► Description:
LD5H precast lightweight wall panel machine includes 2 Concrete Mixer, A Screw Conveyor, A Foam
Generator And A Foam Concrete Pump, adopts advanced centralized control technology, can exactly
adjust the density of foam cement.
The capacity is 5m3/h, which is specially designed for CLC brick block making, and this machine
with Auto-Weighting System, can automatically measure cement, sand, etc. raw material, very
convenient to operate.
Also, this lightweight wall panel machine making machine can Dilute Foam Agent Automatically based
on designed ratio, very easy to operate and use.
► Application:
used in roof insulation is with warm keeping, heat insulating function, it’s effect is 20-30 times the
ordinary material, which keeps the room temperature of top floor the same as other floors, warm in
winter and cool in summer.
2. LD5H CLC foam concrete machine can be used in producing various specifications of cement foam
board, cement foam bricks and external wall insulation material. Also applied for insulation, moisture
proofing, anti-corrosion of water, heating and transmission oil pipeline, insulation of low temperature
cold store and refrigerated depot section, can also be used in filling tunnel and mine internal voids
etc.
3. LD5H is a ideal equipment for light foam cement producing, applied for large area field of
insulating layer in floor heating constructions, with daily 80m3 capacity, vertical conveying distance
40m, horizontal 300m, flexible density at 250-1600kg/m3. The surface will flow smooth naturally.
► Features:
1. Installed with walk round, can move on the ground or mounted on the truck.
2. High-quality wear resistant components for long service-life and also provide after-sales service security.
3. Can be used as cement foaming machine and mortar pump.
4. Automatically control the proportion of the various components, density of foaming cement easy to
be adjusted.
5. Duplex mixer system to ensure continuous production and uniform density. This design can
improve capacity and save labor greatly.
► Technical Data:
Model
|
LD5H
|
Max. theoretical concrete put(m³/h)
|
5
|
Motor power(kw)
|
11
|
Theoretical vertical conveying height(m) | 40 |
Theoretical level transmission distance(m) | 300 |
Mixer tank capacity(L) | 200 & 500 |
Filling height(mm) | 880 |
Foam concrete machine dimension(mm) | 2100×1340×1390 |
Total weight(kg)
|
1500 |
