► Description:
and then mix them in a certain proportion, press them into transmission pipelines through hydraulic
cylinder; According to a certain proportion foam mixed with water and then mixed with compressed
air by the high-pressure pump; In the pipeline it form the high-density foam and meticulous, at last form
the foam cement with the slurry in the pipeline. And the foam concrete slurry could be used for
cast-in-situ wall, tunnel filling, foundation pit filling, platform backfilling, making blocks etc.
► Application:
1. Thermal flooring;
2. Garden and rockeries;
3. Foam concrete block;
4. Sewers and Drains filling;
5. Thermal insulation roofing;
6. Horizontal floor heightening;
7. Platform filling and mending;
8. Cellar, basement and arch filling;
9. External wall thermal insulation;
10. Playground and track construction;
11. Water tank and fuel tank building;
12. Sound insulation and fire protection walls;
13. Sound insulation layer, tunnel lining filling;
14. Upstanding beam foundation ditches filling;
15. Foamed concrete precasting ,hollow wallboard casting.
► Features:
1. Foam cement block making machine could mixing variable materials, such as cement, fly ash, sand
pulp, sand stone, perlite, and slag etc;
2. Variable speed mixing and internal structure alteration make its installation easy and mixing
frequency high, it saves energy;
3. CLC block making machine is specially mixing blades, mixing the material toughly, storage in its
bottom is less than 10mm, no material left on the four walls internal the mixing drum.
► Technical Data:
Model
|
LM1000
|
Max.Output | 5m3/h |
Material input volume | 1000L |
Mixing speed | 6-8min/batch |
Mixer motor power | 1.5kw |
Max. Particle Size of Aggregates | 8mm |
